NASA’s Hubble Watches ‘Spoke Season’ on Saturn

3 min read

NASA’s Hubble Watches ‘Spoke Season’ on Saturn

Colorful stripes in yellow, white, reddish-orange, pink, and green cover the planet. Saturn is tilted slightly toward us allowing the Sun to illuminate the top of its rings. The planet's shadow is cast toward the back and left of the planet. Saturn's moons Dione, and Enceladus are visible to its upper right, while its moon Mimas is just below and to the left of the planet's rings.
This NASA Hubble Space Telescope photo of Saturn reveals the planet’s cloud bands and a phenomenon called ring spokes.
NASA, ESA, STScI, Amy Simon (NASA-GSFC)

This photo of Saturn was taken by NASA’s Hubble Space Telescope on October 22, 2023, when the ringed planet was approximately 850 million miles from Earth. Hubble’s ultra-sharp vision reveals a phenomenon called ring spokes.

Saturn’s spokes are transient features that rotate along with the rings. Their ghostly appearance only persists for two or three rotations around Saturn. During active periods, freshly-formed spokes continuously add to the pattern.

In 1981, NASA’s Voyager 2 first photographed the ring spokes. NASA’s Cassini orbiter also saw the spokes during its 13-year-long mission that ended in 2017.

Hubble continues observing Saturn annually as the spokes come and go. This cycle has been captured by Hubble’s Outer Planets Atmospheres Legacy (OPAL) program that began nearly a decade ago to annually monitor weather changes on all four gas-giant outer planets.

Hubble’s crisp images show that the frequency of spoke apparitions is seasonally driven, first appearing in OPAL data in 2021 but only on the morning (left) side of the rings. Long-term monitoring show that both the number and contrast of the spokes vary with Saturn’s seasons. Saturn is tilted on its axis like Earth and has seasons lasting approximately seven years.

“We are heading towards Saturn equinox, when we’d expect maximum spoke activity, with higher frequency and darker spokes appearing over the next few years,” said the OPAL program lead scientist, Amy Simon of NASA’s Goddard Space Flight Center in Greenbelt, Maryland.

This year, these ephemeral structures appear on both sides of the planet simultaneously as they spin around the giant world. Although they look small compared with Saturn, their length and width can stretch longer than Earth’s diameter!

“The leading theory is that spokes are tied to Saturn’s powerful magnetic field, with some sort of solar interaction with the magnetic field that gives you the spokes,” said Simon. When it’s near the equinox on Saturn, the planet and its rings are less tilted away from the Sun. In this configuration, the solar wind may more strongly batter Saturn’s immense magnetic field, enhancing spoke formation.

Planetary scientists think that electrostatic forces generated from this interaction levitate dust or ice above the ring to form the spokes, though after several decades no theory perfectly predicts the spokes. Continued Hubble observations may eventually help solve the mystery.


This Hubble Space Telescope time-lapse series of Saturn images (taken on October 22, 2023) resolves a phenomenon called ring spokes appearing on both sides of the planet simultaneously as they spin around the giant world. The video zooms into one set of spokes on the morning (left) side of the rings. The spokes are transient features that rotate along the ring plane. The spokes may be a product of electrostatic forces generated by the interaction of the planet’s magnetic field with the solar wind. This interaction levitates dust or ice above the ring to form the spokes. Credit: NASA, Amy Simon (NASA-GSFC);
Animation:
Joseph DePasquale (STScI)

The Hubble Space Telescope is a project of international cooperation between NASA and ESA. NASA’s Goddard Space Flight Center in Greenbelt, Maryland, manages the telescope. The Space Telescope Science Institute (STScI) in Baltimore, Maryland, conducts Hubble and Webb science operations. STScI is operated for NASA by the Association of Universities for Research in Astronomy, in Washington, D.C.
